Description: The Yellow Digital Clamp Meter (Mini) by Sun Top is a compact, user-friendly measuring instrument designed for industrial and home applications. This mini clamp meter allows for non-contact current measurement, enabling users to quickly and safely measure AC current, voltage, resistance, and continuity without needing to disconnect any wires. Its yellow casing makes it highly visible in industrial environments, ensuring safety and ease of use. Whether for basic troubleshooting or advanced electrical testing, this tool offers the convenience and accuracy needed for a variety of tasks.
Specifications:
Specification
Details
Model Name/Number
Sun Top, Digital Clamp Meter (Mini)
Display Type
LCD digital display
Current Range
AC Current: 0.1A to 400A
Voltage Measurement
AC/DC Voltage: 0.1V to 600V
Resistance Range
0.1Ω to 40MΩ
Accuracy
±(1.5%+2) for current, voltage, and resistance
Clamp Diameter
40mm (1.57 inches)
Power Supply
2 x 1.5V AAA batteries
Operating Temperature
0°C to 40°C (32°F to 104°F)
Dimensions
180mm x 70mm x 40mm
Weight
220g
Material
ABS Plastic (Yellow Color)
Safety Category
CAT III 600V
Measuring Features
AC Current, DC/AC Voltage, Resistance, Continuity Test
Display Resolution
0.1A for current, 0.1V for voltage, 0.1Ω for resistance
Key Features:
Compact Design: The mini clamp meter is designed to be portable, lightweight, and easy to handle, making it perfect for both industrial and home use.
Wide Measurement Range: Measures AC current up to 400A, AC/DC voltage up to 600V, and resistance up to 40MΩ for versatile usage in electrical testing.
Non-Contact Measurement: The clamp design allows you to measure current without needing to disconnect any wiring or conductors, increasing safety during use.
Clear Digital Display: Features a large LCD screen for easy-to-read results with clear digital output.
Continuity Test: Equipped with a continuity test function to check for broken circuits or faulty connections.
High Accuracy: The meter offers high measurement accuracy for current, voltage, and resistance, ensuring reliable results.
Safety Features: Built with CAT III 600V safety ratings, making it safe to use on most industrial electrical circuits.
Easy to Use: Simple operation with easy-to-access buttons and a user-friendly interface.
Applications:
Electrical Troubleshooting: Use the clamp meter to quickly check for issues like short circuits, overcurrent, and voltage discrepancies.
Home Electrical Systems: Ideal for DIY electrical work, home inspections, and power consumption monitoring.
Industrial Equipment Maintenance: Perfect for checking electrical equipment, machines, and motor circuits in industrial environments.
HVAC Systems: For checking the power consumption of air conditioners, heating systems, and similar devices.
Automotive Applications: Can also be used for automotive electrical troubleshooting, such as checking alternators and wiring.
Usage Tips:
Measuring Current: Simply clamp the meter around the conductor you want to measure the current of, ensuring the clamp fully closes around the wire without touching any other parts.
Voltage Measurement: For DC/AC voltage measurement, insert the test leads into the appropriate ports and touch the leads to the points where the voltage is to be measured.
Resistance Measurement: Use the resistance function to check the integrity of a circuit or test components like fuses, diodes, or resistors.
Continuity Test: When performing a continuity test, listen for the beeping sound or look for the visual indication on the display that tells you whether the circuit is complete or open.
Safety Instructions:
Always ensure the current and voltage levels fall within the specified limits to avoid damaging the meter.
Never measure current on a live wire unless the clamp is correctly placed and the device is rated for the application.
Avoid using the meter in environments with high humidity or extreme temperatures to prevent damage.
Always turn off the meter when not in use to conserve battery life.
Use the safety insulated test leads when measuring high voltages to avoid electrical shock.
Applications Example: This Yellow Digital Clamp Meter (Mini) by Sun Top is the go-to tool for technicians, engineers, and home electricians for everyday electrical tasks. Whether you are diagnosing a malfunctioning appliance, checking a power distribution panel, or performing routine maintenance on industrial machinery, this meter provides essential measurements at your fingertips.
Safety Instructions:
Ensure the clamp meter is in the OFF position when making any adjustments to settings or replacing the battery.
When measuring high-current or high-voltage circuits, follow standard safety precautions such as using insulated gloves and working in dry conditions.
